CFM Industries Chevy/GMC K5 Blazer & Jimmy Gas Tank Skidplate – Heavy Duty & Extreme Duty Options
$449.95
Protect your fuel system with the CFM Industries Heavy Duty Gas Tank Skidplate for Chevy/GMC K5 Blazers and Jimmys. Factory sheetmetal skidplates are thin and prone to damage — this upgrade delivers serious protection with 3/16-inch hot rolled steel and an optional Extreme Duty version featuring a 1/4-inch thick bottom plate.
Laser cut, precision formed, and available in either a weld-it-yourself kit or fully welded, ready-for-paint version, this skidplate is built in the USA to handle the toughest off-road abuse. Whether you’re rock crawling, snow wheeling, or overlanding, this is the upgrade your K5 needs to keep moving forward.
⚠️ Note: Made to order. Please allow 1–2 weeks fabrication plus shipping time.
Specifications
- Vehicle Fitment: Chevy/GMC K5 Blazer & GMC Jimmy (1973–1991)
- Material: 3/16" hot rolled, pickled & oiled steel
- Options:
- Heavy Duty – 3/16" plate all around
- Extreme Duty – 3/16" sides & 1/4" bottom plate
- Assembly:
- Un-welded (Weld-It-Yourself kit)
- Fully welded (ready for paint or powder coat)
- Manufacturing:
- CNC laser cut and formed in-house, USA made
- Lead Time: Made to order, 1–2 weeks fabrication + shipping
How to Use / Install
- Remove the factory skidplate from your K5 Blazer/Jimmy (if equipped).
- Paint or powder coat your new skidplate for corrosion protection before final install.
- Position the skidplate under the gas tank and align mounting points.
- Bolt into place using factory or upgraded hardware.
- For un-welded kits: weld the assembly before steps 2–4.
Additional Details
- Provides far greater protection than thin OEM sheetmetal skidplates.
- Extreme Duty upgrade is ideal for hardcore wheeling, big tires, and high-clearance builds.
- Made in the USA with precision CNC laser cutting and in-house forming.
- Ships raw steel, ready for your choice of finish.
